Building Auth-Enabled QR Code Apps with Release0 (QR Bolt Case Study)

5 minutes read

Try the Demo →

QR Bolt isn’t just a QR code generator — it’s a smart, user-aware agent that remembers users, stores their content, and provides dynamic features using Release0 blocks. In this blog, we’ll dissect how it combines authentication, data persistence, and multi-channel delivery in a seamless experience.


🧠 What Makes QR Bolt Special?

QR Bolt demonstrates a high-level use of Release0’s stack by offering:

  • Google Sign-In (OAuth 2.0) with session handling
  • Persistent vs. Guest sessions with fallback logic
  • Cloud storage via Google Sheets
  • Multi-channel QR delivery: chat image, email, and direct download
  • Client-side scripting for token handling and URL encoding

👥 Two Flows: Logged-in vs. Guest

🔐 Sign in with Google

  • User authenticates via Google OAuth.
  • Their QR code is saved in Google Sheets.
  • They receive it by email.
  • On next visit, the saved QR auto-loads.

🧪 Continue as Guest

  • Skips login for speed.
  • QR is generated instantly.
  • No save or email — only instant download.

This dual flow ensures the best of both UX worlds: speed and persistence.


🔗 Google OAuth 2.0 Integration

The agent constructs the Google login URL dynamically using a Set Variable block with isCode: true. It uses:

  • client_id
  • redirect_uri
  • scope=email profile
  • response_type=code

Then it Redirects the user to Google.

Once redirected back, it processes the code URL parameter:

  • Sends it to Google's token API using a Webhook Block
  • Decodes the returned id_token using a JavaScript function (decodeIdToken) to extract the user email and name

📦 Persistent User Data with Sheets

For logged-in users, QR Bolt saves their QR code metadata in a Google Sheet:

  • Email
  • Image URL
  • Timestamp

The next time the user logs in, the agent uses Get data from sheet to find their last QR, and shows it automatically.


🖼️ Multi-Channel Delivery

When a QR code is generated:

  • It’s shown immediately in the chat
  • It’s emailed as an image attachment
  • It’s opened in a new tab via a Redirect block for download

🧠 Code-Like Block Logic

buildGoogleAuthURL()

A Set Variable block assembles the Google login URL with:


_10
const base = "https://accounts.google.com/o/oauth2/v2/auth";
_10
const redirect = encodeURIComponent(window.location.href);
_10
return `${base}?client_id=xxx&redirect_uri=${redirect}&scope=email%20profile&response_type=code`;

decodeIdToken()

Another Set Variable block decodes the JWT to extract profile info:


_10
const payload = JSON.parse(atob(id_token.split(".")[1]));
_10
return { name: payload.name, email: payload.email };


🧠 Key Block Highlights

Block TypeUse
Set Variable (isCode)Build login URL + decode tokens
RedirectSend to Google / Open image
WebhookExchange auth code for token
ConditionBranch logic based on code presence
SheetsSave and retrieve user data
Send EmailDeliver QR as attachment

✨ Try It Live

Launch QR Bolt

Login and test how your last QR is remembered and delivered via email. Then try guest mode — fast, disposable, no memory.


🚀 Why This Matters

QR Bolt is a showcase of what Release0 can do:

  • Combine frontend auth
  • Call APIs securely
  • Build persistent memory using Sheets
  • Deliver output via multiple channels

All without backend code. It’s a low-code full-stack experience — and it runs right inside a chat.

Let us know how you’re building smart flows with Release0 + OAuth!
